| Card dimensions |
card: 85 x 54 mm (ISO 7031/CR 80) up to 210 x 148 mm (DIN A5) |
| Pack height |
max. 5.00 mm
|
| Production speed |
up to 100 cards/minute (6,000 cards/hour) |
| Sealing process |
4-sided ultrasonic security sealing
|
| Film specification |
BOPP 35µm,
center folded film: inner diameter: 76 mm, outer diameter: 300 mm, width max. 240 mm
flat film: inner diameter: 76 mm, outer diameter: 300 mm, width max. 480 mm (film folding device) |
| Drive |
elau servo-drive
|
| Control |
Industrial PC (IPC) with touchscreen (Windows CE)
|
| Electrical power requirements |
3 x 400 V / 3 AC / N / PE / 50 Hz (standard)
10 kVA / 16 A |
| Air requirements |
6 bar (dry and oil free)
consumption: 350 l/min |
| Machine dimensions (LxWxH) / weight |
7.50 x 3.35 x 2.00 m / 2,000 kg |
| Options |
Customized sealing seam design
Collating machine with feeders
Film folding module
Header packages with eurohole
Flap closing unit with self-adhesive strip applicator
Card Monitoring Systems (CMS)
Inline connection to different types of overwrapping systems
Stacking unit with outfeed conveyor |
